809 REbeL CHROME

Chrome

PATENT PENDING

WHEEL SPECIFICATIONS

Part Number Size Backside Offset Bolt Circle Bore
809-7905C+12 17x9 5.47 12 5-5.0, 5-5.5 87
809-7933C+12 17x9 5.47 12 6-120, 6-135 87
809-7935C+12 17x9 5.47 12 6-5.5, 6-135 106.1
809-7935C+25 17x9 5.98 25 6-135, 6-5.5 106.1
809-7982C+12 17x9 5.47 12 8-6.5 125.2
809-7987C+12 17x9 5.47 12 8-170 125.2
809-8904C+12 18x9 5.47 12 5-5.0, 5-4.5 81.5
809-8905C+12 18x9 5.47 12 5-5.0, 5-5.5 87
809-8933C+12 18x9 5.47 12 6-120, 6-135 87
809-8935C+12 18x9 5.47 12 6-5.5, 6-135 106.1
809-8935C+18 18x9 5.71 18 6-135, 6-5.5 106.1
809-8950C+18 18x9 5.71 18 5-150 110.3
809-8982C+12 18x9 5.47 12 8-6.5 125.2
809-8987C+12 18x9 5.47 12 8-170 125.2
809-8904C12 18x9 4.53 -12 5-5.0, 5-4.5 81.5
809-8905C12 18x9 4.53 -12 5-5.0, 5-5.5 87
809-8981C12 18x9 4.53 -12 8-6.5 125.2
809-8935C12 18x9 4.53 -12 6-5.5, 6-135 106.1
809-2905C+18 20x9 5.71 18 5-5.0, 5-5.5 87
809-2933C+18 20x9 5.71 18 6-120, 6-135 87
809-2935C+18 20x9 5.71 18 6-5.5, 6-135 106.1
809-2935C+25 20x9 5.98 25 6-135, 6-5.5 106.1
809-2950C+25 20x9 5.98 25 5-150 110.3
809-2982C+18 20x9 5.71 18 8-6.5 125.2
809-2987C+18 20x9 5.71 18 8-170 125.2
809-2905C12 20x9 4.53 -12 5-5.0, 5-5.5 87
809-2981C12 20x9 4.53 -12 8-6.5 125.2
809-2935C12 20x9 4.53 -12 6-5.5, 6-135 106.1
